Savoia index  Pure Sine Wave Power Inverters



To get 220V-50hz or 110V-60hz from 12-24VDC batteries

SINGLE PHASE PURE SINE WAVE INVERTER

Single phase PSW inverters



Model


WS12500


WS24500

WS241000

WS481000

WS482000

WS483000

DC Input Voltage (V Dc)


12V


24V

24V

48V

48V

48V

Other Voltage is Available, Please Confirm Before Order

Continuous Power Rating


500W


500W

1000W

1000W

2000W

3000W

Typical Efficiency

96%

Total Harmonic Distortion

3%

Output Wave

Pure Sine Wave

Output Voltage

Single phase  220V/50HZ  120V/60HZ

Output Voltage Precision

220V 3%

120V 3%

Output Frequency Precision

50 0.1%

60 0.1%

Overload Ability

120%  60 Seconds

Protection

Input Polarity Reverse Protection ;Lower Voltage Protection ;

Over Voltage Protection; Over Load Protection ;

Short Circuit Protection; Over Heating Protection

Isolation

Input VS Output: AC 1500V 60 Seconds

Operation  Temperature

0%90%, -250C+550C

Humidity

0%90%, Non-condensing

Noise

45db

Operation Altitude (m)

2500


THREE PHASE PURE SINE WAVE INVERTER


3Phase PSW inverters


Model


WS485000


WS24010000

WS24010000-3

WS48020000-3

WS48030000-3

DC Input Voltage (V Dc)


48V


240V

240V

480V

480V

Other Voltage is Available, Please Confirm Before Order

Continuous Power Rating


5kw


10kw

10kw

20kw

30kw

Typical Efficiency

92%

Total Harmonic Distortion

3%

Output Wave

Pure Sine Wave

Output Voltage

Single Phase

120V/60Hz 220V/50Hz

Three Phase

480V/60Hz  380V/50Hz

Output Voltage Precision

220V 3%,    120V 3%

Output Frequency Precision

50 0.1%,    60 0.1%

Overload Ability

10 seconds 120%

AC Input (Optional)

By Pass(Optional)

Single phase: 120V/60Hz;220V/50Hz; 240V/50Hz

(5KW,10KW also can provide three phase)

Protection

Input Polarity Reverse Protection ;Lower Voltage Protection ;

Over Voltage Protection; Over Load Protection ;

Short Circuit Protection; Over Heating Protection

Communication Interface

RS232/485(Optional)

Isolation

  Input VS Output: AC 1500V 60 Seconds

Operation  Temperature

-250C+550C

Humidity

0%90%,Non-condensing

Noise

50Db

Operation Altitude (m)

2500


email: tec@savoiapower.com
2/6/2017
